توضیحات
| Dimensions (W x H x D) | 30.4 mm x 53 mm x 80 mm |
| Sensing distance | 10 mm 1) |
| Housing design (light emission) | Rectangular |
| Light source | LED, RGB 2) |
| Wave length | 470 nm, 525 nm, 640 nm |
| Light emission | Long and short side of housing, exchangeable |
| Light spot size | 1.2 mm x 4.2 mm |
| Light spot direction | Vertical 3) |
| Adjustment | Teach-in button |
| Teach-in mode | Static 2-point teach-in |
- 1) From front edge of lens.
- 2) Average service life: 100,000 h at TU = +25 °C.
- 3) In relation to long side of housing.
