| Product characteristics |
| Electrical design |
PNP |
| Output function |
complementary |
| Sensing range [mm] |
20 |
| Housing |
rectangular |
| Dimensions [mm] |
40 x 40 x 54 |
| Electrical data |
| Operating voltage [V] |
10…36 DC |
| Current consumption [mA] |
< 25 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Outputs |
| Electrical design |
PNP |
| Output function |
complementary |
| Max. voltage drop switching output DC [V] |
2.5 |
| Max. leakage current [mA] |
0.1 |
| Permanent current rating of switching output DC [mA] |
200 |
| Switching frequency DC [Hz] |
100 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
| Detection zone |
| Sensing range [mm] |
20 |
| Operating distance [mm] |
0…16.2 |
| Accuracy / deviations |
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.4 / copper: 0.3 |
| Hysteresis [% of Sr] |
1…20 |
| Operating conditions |
| Ambient temperature [°C] |
-25…70 |
| Protection |
IP 67 |
| Tests / approvals |
| EMC |
| EN 61000-4-2 ESD |
8 kV CD / 6 kV AD |
| EN 61000-4-3 HF radiated |
10 V/m |
| EN 61000-4-4 Burst |
2 kV |
| EN 61000-4-5 Surge |
0,5 kV line to line, Ri: 2 Ohm |
| EN 61000-4-6 HF conducted |
10 V |
| EN 55011 |
class B |
|
| MTTF [years] |
1270 |
| UL approval |
| Ta |
-25…70 °C |
| Enclosure type |
Type 1 |
| voltage supply |
Class 2 |
| File number UL |
E174191 |
|
| Mechanical data |
| Weight [g] |
146.5 |
| Housing |
rectangular |
| Sensing face |
5 positions selectable |
| Mounting |
flush mountable |
| Dimensions [mm] |
40 x 40 x 54 |
| Materials |
PA |
| Displays / operating elements |
| Display |
| switching status |
1 x LED, yellow |
| operation |
1 x LED, green |
|
| Remarks |
| Pack quantity |
1 pcs. |
